LOXEAL 83-21 THREAD LOCKER - 50 ML, 9316889011394
Anaerobic adhesive for metals, fast polymerisation and high mechanical resistance to seal and lock threaded joints and cylindrical couplings.
Provides a high chemical resistance to heat and thermal shocks, vibrations, and ageing. The product is approved for use as a sealant in the presence of gaseous oxygen to 20 bar at 60 °C
Stickers of high resistance this line allows the mounting of cylindrical which pairing: bearings, gears, pulleys, pins, bushings.
Provides high torque transmission. Replace, Serated trees, welding sticks. Seals the giuno eliminating the corrosion from external influences and contact.Can paste different materials between them. Resist high temperatures (up to 230 °C).
Thread Diameter Max Game Max diametrale: M20 - 0.15 mm
Product description
High resistance: Permanent Mounting Diameter Max - Max diametrale game thread: M20 - 0.15 mm viscosity (+ 25 °C MPa S): 400 - 600 Low thixotropy Green/F hardening handling minutes time: 2 - 5 hours functional hardening time: 1 - 3 torque (ISO 10964) initial N M: 25 - 35 torque (ISO 10964) residual N M: 50 - 70 sliding (ISO 10123) N/mm2 Resistance: 25 - 35 °C Temperature of use: -55 + 175 locking adhesive for use instructions fixative 83 - 21 loxeal 1. Wipe clean surfaces with loxeal 10 cleaner and allow to dry. 2. If the games are high and/or metals are passive polymerisation of sticker might be slow, use the specific Activator 11 for reduce the time of polymerization. 3. Interference: If you need heat the female coupling for the assembly, apply the sticker on the entire surface of the male. In the case it is necessary to cool the male, apply the sticker on the entire surface of the female. If you must carry out both the heating that the cooling to place the sticker on the cooled making sure that there is no condensation. 4. Coupling forced to press: Apply the sticker on both the male female, assemble the parts to the desired pressure. 5. Coupling free: the original sticker must be applied along the circumference of the part of the male and fully within the female, pairing with twisting motion to allow the adhesive to distributes evenly. 6. Before subjecting the pieces assembled stresses to wait the time that the sticker has achieved the functional strength. If used as a sealant adhesive: Apply a kerb of 360 ° between the first and the second of the male thread, screw on Female giving the desired pair of screw. For heavy diameter to apply sticker on both the male thread and fittings that on the female.
